28mm Pent Roof Gazebo 255 - With Integral Summerhouse
Play Video
Pictures 1 and 2 show the 9'10"x20'6" (3.0x6.2m) gazebo with optional EPDM roof. The pictures show what may be achieved using coloured preservatives. Picture 3 shows the optional paint colours available.


These premium quality gazebos are available in sizes between approximately 8'2"x14'4" and 12'9"x28'9" (2.5x4.4m and 3.9x8.8m). The price includes a large canopy with an integral 9'10" (3.0m) wide summerhouse. These substantial gazebos feature a superb quality joinery door, double glazing and 28mm thick wall logs. Internal skirting boards and an aluminium door threshold are also included. This range of gazebos features a unique wall jointing system, with each wall log slotting into sturdy and modern looking 120x120mm posts. The posts feature full length concealed aluminium connectors. A choice of preservative treatments are available as options. Roof options include a durable and low maintenance one piece EPDM rubber roof surface. Detailed instructions are supplied for DIY self assembly. We offer fitting as a low cost option in many areas.

Back to the Top
  • Individually made to order. If you choose a non standard door and window position we will contact you before your order is processed to confirm your requirements.
  • All timber used in the construction of this gazebo originates from sustainable forests
  • Integral summerhouse approximately 9'10" wide (3.0m) on all sizes
  • 14'4" wide (4.4m) gazebos include a canopy approximately 4'6" wide (1.4m) with 1 corner post
  • 16'0" wide (4.9m) gazebos include a canopy approximately 6'2" wide (1.9m) with 1 corner post
  • 17'8" wide (5.4m) gazebos include a canopy approximately 7'10" wide (2.4m) with 1 corner post
  • 19'3" wide (5.9m) gazebos include a canopy approximately 9'5" wide (2.9m) with 1 corner post
  • 20'6" wide (6.2m) gazebos include a canopy approximately 10'8" wide (3.3m) with 1 corner post
  • 22'2" wide (6.8m) gazebos include a canopy approximately 12'4" wide (3.8m) with 1 intermediate post and 1 corner post
  • 23'10" wide (7.3m) gazebos include a canopy approximately 14'0" wide (4.3m) with 1 intermediate post and 1 corner post
  • 25'6" wide ( 7.8m) gazebos include a canopy approximately 15'7" wide (4.8m) with 1 intermediate post and 1 corner post
  • 27'1" wide (8.3m) gazebos include a canopy approximately 17'3" wide (5.3m) with 1 intermediate post and 1 corner post
  • 28'9" wide (8.8m) gazebos include a canopy approximately 18'11" wide (5.8m) with 1 intermediate post and 1 corner post
  • 11'1" (3.4m) and 12'9" (3.9m) deep gazebos include 1 intermediate post
  • 28mm thick tongued and grooved wall logs
  • Unique patented wall jointing system with concealed aluminium connectors and 120x120mm timber posts
  • Easy assembly of the walls with no nails or screws, which also allows for timber movement
  • Doors and window glazed with annealed glass (no plastic, acrylic, styrene or perspex)
  • Premium double glazed doors and windows with rubber weatherstrips to reduce draughts
  • Doors and windows are joinery made with fully profiled timbers and morticed and tenoned joints throughout
  • Single hinged door, fully glazed with high security mortice lock and lever handles
  • Single door 2'6" wide x 6'4" high (770mm x 1940mm)
  • Durable aluminium door threshold
  • Chrome plated door and window handles
  • 1 top hinged opening window
  • Window size 2'6" wide x 3'9" high (770mm x 1140mm)
  • Partition to create an integral summerhouse
  • Canopy includes a plain fully boarded rear wall as standard
  • As with most log cabins, the roof is supplied unassembled with the rafters and roof boards cut to size
  • These gazebos are untreated as standard
  • Foundation beams ex 3"x2" (70mm x 45mm) pressure treated (lifetime preservative treatment)
  • Floor joists ex 2"x2" (45mm x 45mm) pressure treated (lifetime preservative treatment)
  • Substantial 19mm thick tongued and grooved timber floor boards in the summerhouse (finished size after machining)
  • Internal skirting boards
  • Strong 19mm thick tongued and grooved roof boards (finished size after machining)
  • Substantial timber fascia boards to front, rear and sides
  • Eaves height approximately 7'3" (2230mm)
  • Ridge height approximately 8'2" (2500mm)
  • External roof overhang approximately 7" to all sides (180mm)
  • This building is easy to deliver if access is restricted - all sections will pass through a normal single door

UNIQUE LOG ASSEMBLY: This quality garden room features a unique corner assembly system, which is both attractive and strong and combines the benefits of a log cabin with a conventional summerhouse. Each wall log slots into sturdy 120x120mm posts featuring full length concealed aluminium connector poles. This gives a modern appearance and simplifies the installation. The first log is laid at the bottom and the rest slot into each other, working upwards one log at a time. The logs and the aluminium connectors are precision milled to ensure a neat fit. No screws or nails are required which makes installation easier whilst also allowing for timber movement. The finished corner assembly is strong, weatherproof and draughtproof.

NORDIC SPRUCE: This building is manufactured from 100% Nordic Spruce, the best quality timber used in log cabin construction. Nordic Spruce is grown primarily in the well managed forests of Scandinavia, Siberia and the coldest parts of Northern Europe. The cold climate ensures slow growth. The growth rings are much closer together than trees grown in warmer climates. As a result the timber is heavy and durable with a dense grain pattern. These forests are expertly managed on a sustainable basis so Nordic Spruce is an enviromentally friendly choice.

JOINERY DOORS & WINDOWS: These log cabins feature joinery made door leaves and window sashes with morticed and tenoned joints throughout. This traditional jointing process is commonly used in the housebuilding industry when timber windows and doors are specified. A rebate or mortice is cut out in one piece of wood which precisely matches a tongue or tenon cut in the other piece of wood. Morticed and tenoned joints are the strongest type of joint used in the construction of wooden windows and doors. High quality handles, locks and hinges are also included.

HIGH PERFORMANCE DOORS AND WINDOWS WITH WEATHERSTRIPS: Our high performance premium window and door frames feature weatherstrips to reduce draughts. Weatherstrips are rubber gaskets which are fitted to the door and window frames. The weatherstrips are fitted in the rebates between the fixed outer frames and the hinged parts i.e. the window sashes and door leaves. As the doors and windows are closed the weatherstrips are compressed to form a seal. Heat loss is significantly lower through windows and doors which are fitted with weatherstrips.

LOW LEVEL GLAZING: Low level glazing provides a panoramic view from inside your garden room so you can appreciate your garden fully. With low level glazing you can enjoy a better view of the garden, especially at sites where the garden slopes away.

HEAVY DUTY TONGUED AND GROOVED FLOOR: This cabin includes a heavy duty timber floor with tongued and grooved floor boards and substantial floor joists. Skirting boards are also included to ensure a neat internal finish. The floor joists and tongued and grooved boards are supplied loose for fast assembly on site. Unlike many log cabin floor kits, all timber is cut to size which saves time during installation. It also ensures that there are no visible joins in the finished floor. The floor is assembled quickly with no visible joints. With some cheaper cabins the boards must be cut to fit on site. This takes much longer and many of the joins are visible afterwards.

PRESSURE TREATED FOUNDATION BEAMS: Substantial foundation beams are laid on the base to support the walls. This ensures that the wall logs are not in contact with the ground. The foundation beams are pressure treated for durability. Pressure treatment is a lifetime preservative treatment. The preservative is forced into the timber under pressure in a vacuum and penetrates below the surface. All other treatments apply a coat of stain to the surface of the timber only. With pressure impregnated timber, the chemicals are permanently fixed in the wood. Tanalith E is the most popular preservative used so pressure treated wood is often described as tanalised. With the foundation beams this log cabin can be built without a floor if required.

SIZES - LENGTH AND WIDTH: Sizes are sometimes rounded to the nearest nominal size for ease of reading but the correct external wall sizes are listed alongside the price. The first dimension listed is the depth and the second dimension is the width. The depth refers to the sides. The width refers to the fully boarded rear wall. All sizes quoted are the external gazebo sizes and do not include any roof overhang, unless stated otherwise. Many other suppliers quote the overall roof size which is much larger. All sizes are approximate.
