Metal Shed 374 - Apex Roof, Double Door, Galvanized Steel

Metal Shed 374 - Apex Roof, Double Door, Galvanized Steel
1
2
3
4
5
6
7
Picture 1 shows the standard 9'x8' shed. Pictures 2 and 3 show the standard 9'x6' shed. Pictures 4 and 5 show close up views of the 4" thick ridge beam and the external cladding. Picture 6 shows the 6" wide door threshold slotted over the foundation rail and fixed into the plastic base.

Summary:

This great value metal shed is 9'x6', 9'x8', 9'x10' or 9'x12 with an attractive grey coloured external finish. Heavier than most other comparable metal sheds, all framing and cladding is hot dip galvanized steel. The cladding and doors are also resin coated on both sides. Large sliding double doors are included in the 9' wide wall with lockable handles and a heavy duty threshold. Strong foundation rails are also included. The strong roof structure features 4" thick rafters and ventilated gables. All fixings and instructions are included. Options include a unique timber base, a galvanized steel base kit which makes laying a concrete floor easier and a selection of base anchor fixings to ensure that your shed is fixed down securely. Accessories include shelves, tool racks and tool hooks.

LIMITED STOCK - SELLING FAST!

Summary:

This great value metal shed is 9'x6', 9'x8', 9'x10' or 9'x12 with an attractive grey coloured external finish. Heavier than most other comparable metal sheds, all framing and cladding is hot dip galvanized steel. The cladding and doors are also resin coated on both sides. Large sliding double doors are included in the 9' wide wall with lockable handles and a heavy duty threshold. Strong foundation rails are also included. The strong roof structure features 4" thick rafters and ventilated gables. All fixings and instructions are included. Options include a unique timber base, a galvanized steel base kit which makes laying a concrete floor easier and a selection of base anchor fixings to ensure that your shed is fixed down securely. Accessories include shelves, tool racks and tool hooks.

LIMITED STOCK - SELLING FAST!

Back to the Top
  • Hot dip galvanized steel framing
  • Hot dip galvanized steel cladding panels with a tough epoxy resin coating inside and out
  • Attractive grey colour to external cladding
  • Contrasting colour to gable fascias and door frame trims
  • Pale colour to all internal cladding
  • Double sliding doors
  • Pair of door handles pre-drilled with 10mm diameter holes to suit most padlocks
  • Vertical, horizontal and diagonal door framing
  • Cladding sheets are corrugated and ribbed for extra strength
  • Corner cladding sheets are folded ninety degrees and overlapped to provide a strong and waterproof corner joint
  • 100mm x 30mm intermediate roof purlins
  • 100mm x 60mm main ridge beam
  • 125mm x 30mm door threshold and ramp
  • 110mm x30mm and 55mm x 30mm foundation rails
  • 120mm wide external ridge cover
  • 4 louvred ventilators are fitted to the front and rear gables for improved ventilation
  • Eaves height approximately 5'6" (1676mm)
  • Ridge height approximately 6'8" (2020mm)
  • Door height approximately 5'4" (1616mm)
  • This shed is easy to deliver if access is restricted - all sections are designed to pass through a normal single door

9'x6' Shed

  • External roof size 9'1" wide x 6'3" deep (2770mm x 1910mm)
  • External cladding size approximately 8'9" wide x 5'11" deep (2670mm x 1810mm)
  • Overall weight 68kg excluding floor - heavier than similar metal sheds supplied by others

9'x8' Shed

  • External roof size 9'1" wide x 8'4" deep (2770mm x 2550mm)
  • External cladding size approximately 8'9" wide x 8'0" deep (2670mm x 2450mm)
  • Overall weight 79kg excluding floor - heavier than similar metal sheds supplied by others

9'x10' Shed

  • External roof size 9'1" wide x 10'6" deep (2770mm x 3190mm)
  • External cladding size approximately 8'9" wide x 10'2" deep (2670mm x 3090mm)
  • Overall weight 92kg excluding floor - heavier than similar metal sheds supplied by others

9'x12' Shed

  • External roof size 9'1" wide x 12'6" deep (2770mm x 3810mm)
  • External cladding size approximately 8'9" wide x 12'2" deep (2670mm x 3708mm)
  • Overall weight 106kg excluding floor - heavier than similar metal sheds supplied by others

HEAVY DUTY CONSTRUCTION: As a rough and ready rule, the more heavy duty a metal shed is the more the carton weighs. These sheds are at least 10% heavier than most similar metal sheds and up to 26% heavier than some others.

GALVANIZED STEEL: All framing and cladding used in the construction of this shed is hot dip galvanized steel. This is a process by which steel is coated with zinc to protect it from corrosion. The cladding is subsequently coated with epoxy resin, partly to protect the zinc coating itself and partly to add colour. The factory finish is described as primer although a top coat is not normally needed. The combination of a zinc coating with epoxy resin provides durable protection even if the surface is scratched.

SIZES - DEPTH AND WIDTH: The external roof sizes are listed alongside the price. The first dimension listed is the width and the second dimension is the depth. The width refers to the angled gable walls at the front and rear including the door wall. The depth refers to the side walls. The external wall sizes may be smaller.
